BLK ICE


Pro
we'll leave the light on for u
Posts: 1709
posted October 09, 2011 09:31 PM
I just hope the motor will fit on my current bike and I can find one cheap
____________
Fastest Stock Motor, Stock Bodywork, Hand Clutch, N/A Super Heavy Hitter on the Planet!
Fastest Stock Motor, Stock Bodywork, Hand Clutch, Nitrous Super Heavy Hitter on the Planet!
Bikeland 1/8 mile 5 sec.N/A Stock Motor Club Member.
Repersenting: BLACK ICE PERFORMANCE and NO QUARTER MOTORSPORTS
Nitrous and Tires Sponsored by: Custom Specialties Cycles
Dyno Tuned by: Garron of ADAMS PERFORMANCE. http://www.adamsperformance.net/
BlackIce Performance: Honor, Freedom, Love of Country!
(I am open to Sponsorship and Product Testing and Review. Contact BlackIce Performance at blackice_performance@yahoo.com) or BlackIce Perf on Facebook

  Ignore this member
codyc_13


Expert Class
Posts: 342
posted October 09, 2011 09:36 PM
Lol, of you only knew what was in my garage right now.
____________
06 zx14, 65", lowered, muzzy pipe, pcIII, air shifter, Litz revalve, Adams cut seat, OSR cut pan 87 pump gas.

8.97 at 149mph

  Ignore this member
DogoZX


Expert Class
Posts: 348
posted October 09, 2011 10:56 PM
quote:
Lol, of you only knew what was in my garage right now.


Is it one of these?...




  Ignore this member
Y2KZX12R


Needs a job
CompetitionCNC.com
Posts: 3762
posted October 10, 2011 03:24 AM
Looks like that was taken during the dress rehearsal last night..... ???
____________
Y2KZX12R
CompetitionCNC.com

  Ignore this member    Click here to visit Y2KZX12R's homepage.
Shane661


Needs a life
Posts: 11494
posted October 10, 2011 04:17 AM        Edited By: Shane661 on 10 Oct 2011 12:21
I guess this is it?:

http://www.motorcycle-usa.com/630/11256/Motorcycle-Article/2012-Kawasaki-Ninja-ZX-14R-First-Look.aspx

Looks...meh. Weight = heavy. Still a ZZR, imo.

Engine tech sounds like a significant improvement.

  Ignore this member
Y2KZX12R


Needs a job
CompetitionCNC.com
Posts: 3762
posted October 10, 2011 04:29 AM        Edited By: Y2KZX12R on 10 Oct 2011 12:40
As long as thats allready posted shane, ill elaborate...

The main journal diameter is 40mm up from 38mm....
____________
Y2KZX12R
CompetitionCNC.com

  Ignore this member    Click here to visit Y2KZX12R's homepage.
Y2KZX12R


Needs a job
CompetitionCNC.com
Posts: 3762
posted October 10, 2011 04:30 AM
the rods are 3mm longer....
____________
Y2KZX12R
CompetitionCNC.com

  Ignore this member    Click here to visit Y2KZX12R's homepage.
Y2KZX12R


Needs a job
CompetitionCNC.com
Posts: 3762
posted October 10, 2011 04:31 AM
the bay to bay breathing windows are revised....
____________
Y2KZX12R
CompetitionCNC.com

  Ignore this member    Click here to visit Y2KZX12R's homepage.
Y2KZX12R


Needs a job
CompetitionCNC.com
Posts: 3762
posted October 10, 2011 04:34 AM
the compression ratio is 12.2 not 12.3 like that article says.....
____________
Y2KZX12R
CompetitionCNC.com

  Ignore this member    Click here to visit Y2KZX12R's homepage.
dakota9498


Pro
Posts: 1181
posted October 10, 2011 04:39 AM
quote:
I guess this is it?:

http://www.motorcycle-usa.com/630/11256/Motorcycle-Article/2012-Kawasaki-Ninja-ZX-14R-First-Look.aspx

Looks...meh. Weight = heavy. Still a ZZR, imo.

Engine tech sounds like a significant improvement.


I agree. I am still excited about the engine, and somewhat excited that most of our stuff should transfer to one of these, but disappointed that there isn't more difference.

But it shouldn't be too expensive to swap some bodywork or buy catalyst stuff when it becomes available and then a motor swap. Or at least a lot less expensive than buying a new one.
____________
2008 ZX14
Never argue with a fool, onlookers may not be able to tell the difference. ~Mark Twain


  Ignore this member
Y2KZX12R


Needs a job
CompetitionCNC.com
Posts: 3762
posted October 10, 2011 04:41 AM
The deck height has been raised.... !!!!!
____________
Y2KZX12R
CompetitionCNC.com

  Ignore this member    Click here to visit Y2KZX12R's homepage.
Shane661


Needs a life
Posts: 11494
posted October 10, 2011 04:42 AM
quote:
The deck height has been raised.... !!!!!



NICE!!!

  Ignore this member
Y2KZX12R


Needs a job
CompetitionCNC.com
Posts: 3762
posted October 10, 2011 04:47 AM
Cams are bigger...

Intake was 9.1mm lift, is now 9.3mm
Exhaust was 8.5mm lift, is now 9.3mm lift
Cam chain is longer and stronger with new gears and guides....
____________
Y2KZX12R
CompetitionCNC.com

  Ignore this member    Click here to visit Y2KZX12R's homepage.
Y2KZX12R


Needs a job
CompetitionCNC.com
Posts: 3762
posted October 10, 2011 04:49 AM
the header has been retuned.....

The old primairy was 1.5" the new one is 1.5" stepped to 1.681" with a new collector....
____________
Y2KZX12R
CompetitionCNC.com

  Ignore this member    Click here to visit Y2KZX12R's homepage.
dakota9498


Pro
Posts: 1181
posted October 10, 2011 04:51 AM
Slipper clutch
____________
2008 ZX14
Never argue with a fool, onlookers may not be able to tell the difference. ~Mark Twain


  Ignore this member
Y2KZX12R


Needs a job
CompetitionCNC.com
Posts: 3762
posted October 10, 2011 04:56 AM
The throttle bodies are still 44 mm..... so this means that there should be another 8 hp when you switch over to our bored 47 mm throttle bodies just like in the gen 1 zx14's.
____________
Y2KZX12R
CompetitionCNC.com

  Ignore this member    Click here to visit Y2KZX12R's homepage.
dogg24


Expert Class
Posts: 322
posted October 10, 2011 04:57 AM
quote:
the header has been retuned.....

The old primairy was 1.5" the new one is 1.5" stepped to 1.681" with a new collector....


So does that mean the exhaust systems will transfer over?
____________
2012 ZX14R SE, Streetmeg, PCV

  Ignore this member
Y2KZX12R


Needs a job
CompetitionCNC.com
Posts: 3762
posted October 10, 2011 04:58 AM
I cant say for sure,,,,, but very likely.
____________
Y2KZX12R
CompetitionCNC.com

  Ignore this member    Click here to visit Y2KZX12R's homepage.
dakota9498


Pro
Posts: 1181
posted October 10, 2011 04:59 AM
quote:
The throttle bodies are still 44 mm..... so this means that there should be another 8 hp when you switch over to our bored 47 mm throttle bodies just like in the gen 1 zx14's.


It should affect the new ones a bit more since the displacement, heads, and cams are revised, that will definitely be a great mod.

Did you guys watch the head-to-head video? It was in Vegas, 97 degrees outside, 9.74 at 146...
____________
2008 ZX14
Never argue with a fool, onlookers may not be able to tell the difference. ~Mark Twain


  Ignore this member
Y2KZX12R


Needs a job
CompetitionCNC.com
Posts: 3762
posted October 10, 2011 05:01 AM
with the mains 2mm bigger i will have to see if I can line bore and line hone the gen1 block for the gen2 crank.

Although the added deck height and longer rods are a big improvement as well so......

Might as well just work with the gen2 engine.....
____________
Y2KZX12R
CompetitionCNC.com

  Ignore this member    Click here to visit Y2KZX12R's homepage.
Y2KZX12R


Needs a job
CompetitionCNC.com
Posts: 3762
posted October 10, 2011 05:03 AM
The ports are "polished"....

The chambers are CNC shaped much like the BMW 1000r.....
____________
Y2KZX12R
CompetitionCNC.com

  Ignore this member    Click here to visit Y2KZX12R's homepage.
Y2KZX12R


Needs a job
CompetitionCNC.com
Posts: 3762
posted October 10, 2011 05:04 AM
the rod stroke ratio is 1.77 now.....
up from 1.70 as on a gen 1 +5mm stroker engine....
____________
Y2KZX12R
CompetitionCNC.com

  Ignore this member    Click here to visit Y2KZX12R's homepage.
Y2KZX12R


Needs a job
CompetitionCNC.com
Posts: 3762
posted October 10, 2011 05:06 AM
New MECHANICAL ratchet chain tensioner with hydraulic assist......

This will stop the chain noise from the gen 1 units...
____________
Y2KZX12R
CompetitionCNC.com

  Ignore this member    Click here to visit Y2KZX12R's homepage.
Y2KZX12R


Needs a job
CompetitionCNC.com
Posts: 3762
posted October 10, 2011 05:08 AM
The valves are the same size..... the intake valves are .4mm longer ......
____________
Y2KZX12R
CompetitionCNC.com

  Ignore this member    Click here to visit Y2KZX12R's homepage.
dakota9498


Pro
Posts: 1181
posted October 10, 2011 05:08 AM
Curb weight: 584.3 lbs. and we know that manufacturers fudge these numbers on the low side. I will be disappointed if they don't offer a version without traction control and the slipper clutch. And that new radiator is huge, big improvement for the street, but I see a lot of drag racers buying up the Gen 1 radiators for a little weight savings.
____________
2008 ZX14
Never argue with a fool, onlookers may not be able to tell the difference. ~Mark Twain


  Ignore this member
