BIKELAND > FORUMS > ZX-14.com > Thread: Fitting the Supercharger NEW TOPIC NEW POLL POST REPLY
johnbull


Expert Class
Posts: 314
posted January 14, 2010 11:43 AM
Fitting the Supercharger

After many hours of measuring and machining the supercharger is ready and mounted on the side of the engine in the car with plenty of clearance everywhere and it looks great.

Next step is to start fabriacting the inlet plenum in conjuction with the intercooler.


____________
John Bul Racing. Malta.

  Ignore this member
JDC


Zone Head
Posts: 570
posted January 14, 2010 11:47 AM
Holly shit - nice work!
  Ignore this member
epd345


Pro
Posts: 1490
posted January 14, 2010 11:49 AM
Wow that would make a nice right highway peg on a regular 14!!!
____________
2012 ZX14, Ceramic Coated Brock's CT Meg, PCV, throttlemeister

  Ignore this member
johnbull


Expert Class
Posts: 314
posted January 14, 2010 11:53 AM
quote:
Holly shit - nice work!


Thanks, the credit must all go to Joe at "Doda Engineering" who is doing all the machine work for us.

Just in case you wondered, all that milling was done on manual milling machine & NOT a CNC milling machine. He sure is capable of some fabulous work I must say!
____________
John Bul Racing. Malta.

  Ignore this member
Compton


Zone Head
Posts: 969
posted January 14, 2010 12:17 PM
looks good, did you guys happen to buy a fuel rail from me on ebay???
____________
b.w.
zx14, little longer, little louder, little lower.
08 Busa, just a little longer and louder and lower than the 14

  Ignore this member
johnbull


Expert Class
Posts: 314
posted January 14, 2010 12:25 PM
quote:
looks good, did you guys happen to buy a fuel rail from me on ebay???


Nop, but I think we're going to be needing one!
____________
John Bul Racing. Malta.

  Ignore this member
Compton


Zone Head
Posts: 969
posted January 14, 2010 02:13 PM
Interesting, because i sold one to Malta
____________
b.w.
zx14, little longer, little louder, little lower.
08 Busa, just a little longer and louder and lower than the 14

  Ignore this member
KZScott


Needs a life
high on speed
Posts: 7147
posted January 14, 2010 05:20 PM
nice!
____________
01 ZX-12R 8.84 @ 156.3 no bars, DOT rubber, Pump Gas NA..... turbo 8.47 @ 164
00 ZX-12R 8.62 @ 165.2 no bars, slicks, Pump Gas, 55 shot... turbo 8.32 @173
00 ZX-12R NA 1: 222.04 1.5: 226.39 Loring AFB
00 ZX-12R street turbo 1: 226.5 1.5: 231.6 Loring AFB

  Ignore this member
01smokes


Needs a job
Posts: 2243
posted January 14, 2010 11:00 PM        Edited By: 01smokes on 15 Jan 2010 06:00
Looks good and im sure it will make some good power. The fuel rails from Compton are bad ass i just got mine it yesterday and that thing is a work of art!!!! I kind of dont want to put it on the bike because it looks so nice lol,Thanks again Compton
____________
PayPal, vigilart22@yahoo.com

Email, artvgl@yahoo.com

  Ignore this member
02zx12rbob


Expert Class
Posts: 496
posted January 15, 2010 05:08 AM
Very Nice !
  Ignore this member
gilberjj


Needs a job
Friend of Fast
Posts: 3189
posted January 15, 2010 01:52 PM
quote:
Very Nice !


+1

  Ignore this member
Superman T


Pro
Posts: 1831
posted January 15, 2010 02:15 PM
johnbull - looks good!

  Ignore this member
dubious


Needs a life
Needs more time to ride!
Posts: 8442
posted January 16, 2010 02:37 PM
quote:
quote:
Very Nice !


+1


+2
____________
natural selection.....
destiny will overcome intervention.
Some are not worthy of the effort.

  Ignore this member
davej


Expert Class
Posts: 451
posted January 16, 2010 09:02 PM
Would like to see this finished, are you using the stock intake chamber?
____________
Triumph guy

  Ignore this member
johnbull


Expert Class
Posts: 314
posted January 18, 2010 11:48 AM
quote:
Would like to see this finished, are you using the stock intake chamber?


No, since I am running this motor in a race car I do not have and cannot use the stock intake chamber as on the ZX14 this is part of the motorcycles frame. i.e. the airbox is part of the bikes frame.

We are currently having an inlet chamber fabricated into one piece with the intercooler. This will tie down and seal onto the throttle bodies.

I will post more pics once this is ready.

Does anybody know whether the oem intake air temp. sensor is ok for boost??? Since forced induction temperatures are quite a bit higher that N/A inlet temperatures I was wondering whether the standard sensor is ok to operate at higher temperatures. Anybody had any experience with this??
____________
John Bul Racing. Malta.

  Ignore this member
INTIMIDA2OR


Needs a life
RED rider!
Posts: 12941
posted January 19, 2010 12:52 PM
Wow cool! Now we need to see some #'s
____________
'06 Passion Red ZX-14



*Lee*

  Ignore this member
INTIMIDA2OR


Needs a life
RED rider!
Posts: 12941
posted January 19, 2010 12:54 PM
quote:
quote:
quote:
Very Nice !


+1


+2

+3
____________
'06 Passion Red ZX-14



*Lee*

  Ignore this member
KZScott


Needs a life
high on speed
Posts: 7147
posted January 19, 2010 09:25 PM
quote:


Does anybody know whether the oem intake air temp. sensor is ok for boost??? Since forced induction temperatures are quite a bit higher that N/A inlet temperatures I was wondering whether the standard sensor is ok to operate at higher temperatures. Anybody had any experience with this??


Lyle was telling me a thermocouple may be better suited for reading air box temp, but i beilive that was without any form of aftercooling, so the oem unit may be fine IF you have a really good cooler on it. are you doing water to air? air to air?
____________
01 ZX-12R 8.84 @ 156.3 no bars, DOT rubber, Pump Gas NA..... turbo 8.47 @ 164
00 ZX-12R 8.62 @ 165.2 no bars, slicks, Pump Gas, 55 shot... turbo 8.32 @173
00 ZX-12R NA 1: 222.04 1.5: 226.39 Loring AFB
00 ZX-12R street turbo 1: 226.5 1.5: 231.6 Loring AFB

  Ignore this member
johnbull


Expert Class
Posts: 314
posted January 20, 2010 12:02 PM
An air to air intercooler so it should have good cooling, plus the rotrex charger gives off a LOT LESS heat than a turbocharger does.

Intercooler is nearly ready. Will post pics once done.
____________
John Bul Racing. Malta.

  Ignore this member
KZScott


Needs a life
high on speed
Posts: 7147
posted January 20, 2010 05:40 PM
looking forward to results, ive heard mixed reviews about that brand of super charger
____________
01 ZX-12R 8.84 @ 156.3 no bars, DOT rubber, Pump Gas NA..... turbo 8.47 @ 164
00 ZX-12R 8.62 @ 165.2 no bars, slicks, Pump Gas, 55 shot... turbo 8.32 @173
00 ZX-12R NA 1: 222.04 1.5: 226.39 Loring AFB
00 ZX-12R street turbo 1: 226.5 1.5: 231.6 Loring AFB

  Ignore this member
johnbull


Expert Class
Posts: 314
posted January 22, 2010 11:31 AM
Intercooler is ready fabricated along with intake chamber on throttle bodies and is looking great. We've kept everything as short as possible plus the intercooler has the air scoop above the drivers head throwing air directly on to it.




____________
John Bul Racing. Malta.

  Ignore this member
gilberjj


Needs a job
Friend of Fast
Posts: 3189
posted January 22, 2010 12:35 PM
still looking great!
  Ignore this member
johnbull


Expert Class
Posts: 314
posted January 29, 2010 01:55 AM
We're going to be running a high pressure injection pump with seperate regulator as opposed to the OEM fuel pump but for now we are retaining the OEM injectors.

What fuel pressure do you turbo guys suggest?? We'll be running it with about 7psi of boost at the beginning.
____________
John Bul Racing. Malta.

  Ignore this member
01smokes


Needs a job
Posts: 2243
posted January 29, 2010 08:00 AM
quote:
We're going to be running a high pressure injection pump with seperate regulator as opposed to the OEM fuel pump but for now we are retaining the OEM injectors.

What fuel pressure do you turbo guys suggest?? We'll be running it with about 7psi of boost at the beginning.


Are you using a FMU?
____________
PayPal, vigilart22@yahoo.com

Email, artvgl@yahoo.com

  Ignore this member
johnbull


Expert Class
Posts: 314
posted January 29, 2010 09:07 AM
Nop, just using constant fuel pressure without FMU.
____________
John Bul Racing. Malta.

  Ignore this member
